Creating New 3D Model



Upon calling this command, a new 3D model is created. As when creating a new drawing, you need to assign a name to the created document.

To create new documents, template files are used that are defined in the command "Customize|Settings…", the tab "Files". Those may contain elements and settings that will be automatically created or enabled with the new document creation. In the case when new document settings need to be modified, edit the respective template file or enter another template file name. The prototype files should be placed in the folder …T-FLEX CAD\PROGRAM\TEMPLATE.

One can have an arbitrary number of prototype files, including user-created ones. A new file can be created from a prototype using the "Welcome" dialog box that comes up on starting the T-FLEX CAD application. Otherwise, use a similar dialog "New From..." by calling the command "FP: Create New Document Based on Prototype".
